Quick Answer: Cantilever Apparatus uses a chrome-plated steel bar measuring 100 x 18 x 0.3 cm, marked along its whole length with lines 5 cm apart and fitted with a hook at one end.
Last updated: October 2026
Key Features
Steel bar, chrome plated
Bar size 100 x 18 x 0.3 cm
Lines marked along the whole bar, 5 cm apart
Hook at one end of the bar
Bar held horizontally with its breadth horizontal
Technical Specifications
Specification
Value
Bar
Steel, chrome plated
Dimensions
100 x 18 x 0.3 cm
Markings
Lines 5 cm apart along the whole bar
Fitting
Hook at one end
About This Product
The bar is held horizontally with its breadth flat, and the hook at one end takes the load. Lines every 5 cm along the whole bar make it easy to set and read positions in Applied Mechanics cantilever experiments.
Frequently Asked Questions
Q1. How far apart are the marked lines on the Cantilever Apparatus? The lines on the bar are 5 cm apart.
