Journal Bearing Apparatus Manufacturer,Supplier and Exporter in Ambala
Product Code : EL-TOML-11030
SPECIFICATIONS:
Journal : 50 mm. dia. (nominal)
Bearing : 55 mm. dia.
Weights : 4 adjustable weights
Motor : D.C. shunt Motor, 3,000 RPM.
Control panel : For speed control of Motor
Manometer panel : 16 tube Manometer
DESCRIPTION:
The apparatus consists of a plain steel shaft encased in a bearing and directly driven by a small electric motor.
The bearing is freely supported on the shaft and sealed at motor end.
The motor speed is precisely controlled by control unit and sealed at motor end.
The motor speed is precisely controlled by control unit and can be run in both directions.
The bearing contains twelve equi-spaced pressures tapping around circumference and four along the axis.
All are connected by light flexible plastic tube to the manometer so that the pressure head of all sixteen point can be observed at a time.
The bearing can be loaded by attaching weight to the arm supported beneath it.
EXPERIMENTS:
Observation of the pressure profile at various conditions of load and speed.
Plotting the Cartesian and polar pressure curves.
Plotting the theoretical Summerfield curves.
SERVICE REQUIRED:
Electric Connections : A.C Single Phase, 230v. supply with ear thing.
Stand Alone Space : 1.5m X 1.5m X 4m Height.
